Indicated for use in patients with atherosclerotic disease of the renal arteries following suboptimal percutaneous transluminal renal angioplasty (PTRA) of a de novo or restenotic lesion (≤ 18 mm in length) located within 10 mm of the renal ostium and with a reference vessel diameter of 4.0-7.0 mm. Suboptimal PTRA is defined as ≥ 50% residual stenosis, ≥ 20 mm Hg systolic or ≥ 10 mm Hg mean translesional pressure gradient or flow-limiting dissection.
This product line is serviced by the following clinical division(s):
The products on this website are available for sale in the United States. Reference Part Numbers are not the same in all countries/regions. For products available in other countries, please choose one of our other websites from the region selector at the top of the site or contact your local Cook Medical representative.
Specifications
| Order Number | Reference Part Number |
Instructions for Use (IFU) |
MR Status |
Accepts Wire Guide Diameter inch |
Stent Diameter mm |
Stent Length mm |
More Info |
|---|---|---|---|---|---|---|---|
| 80 cm Rapid-Exchange Delivery System | |||||||
| G18523 | FORX414-14-80-4-12 |
|
|
.014 | 4 | 12 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G18524 | FORX414-14-80-4-16 |
|
|
.014 | 4 | 16 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G18525 | FORX414-14-80-4-20 |
|
|
.014 | 4 | 20 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56958 | FORX414-14-80-5-12 |
|
|
.014 | 5 | 12 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56959 | FORX414-14-80-5-16 |
|
|
.014 | 5 | 16 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56960 | FORX414-14-80-5-20 |
|
|
.014 | 5 | 20 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56962 | FORX414-14-80-6-12 |
|
|
.014 | 6 | 12 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56961 | FORX414-14-80-6-16 |
|
|
.014 | 6 | 16 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56963 | FORX414-14-80-6-20 |
|
|
.014 | 6 | 20 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56964 | FORX414-14-80-7-12 |
|
|
.014 | 7 | 12 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56965 | FORX414-14-80-7-16 |
|
|
.014 | 7 | 16 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56967 | FORX414-14-80-7-20 |
|
|
.014 | 7 | 20 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| 135 cm Rapid-Exchange Delivery System | |||||||
| G18526 | FORX414-14-135-4-12 |
|
|
.014 | 4 | 12 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G18527 | FORX414-14-135-4-16 |
|
|
.014 | 4 | 16 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G18528 | FORX414-14-135-4-20 |
|
|
.014 | 4 | 20 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56966 | FORX414-14-135-5-12 |
|
|
.014 | 5 | 12 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56968 | FORX414-14-135-5-16 |
|
|
.014 | 5 | 16 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56969 | FORX414-14-135-5-20 |
|
|
.014 | 5 | 20 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56970 | FORX414-14-135-6-12 |
|
|
.014 | 6 | 12 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56971 | FORX414-14-135-6-16 |
|
|
.014 | 6 | 16 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56972 | FORX414-14-135-6-20 |
|
|
.014 | 6 | 20 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56973 | FORX414-14-135-7-12 |
|
|
.014 | 7 | 12 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56974 | FORX414-14-135-7-16 |
|
|
.014 | 7 | 16 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
| G56975 | FORX414-14-135-7-20 |
|
|
.014 | 7 | 20 | Expand » |
|
Additional Specs
Description
-
Sheath/
Guiding
Catheter Fr
5.0/6.0
Nominal/
Rated Burst
Pressure atm
8/12
|
|||||||
