Supplied sterile in peel-open packages. Intended for one-time use.
This product line is serviced by the following clinical division(s):
The products on this website are available for sale in the United States. Reference Part Numbers are not the same in all countries/regions. For products available in other countries, please choose one of our other websites from the region selector at the top of the site or contact your local Cook Medical representative.
Specifications
| Order Number | Reference Part Number |
Instructions for Use (IFU) |
MR Status |
Diameterinch |
Length cm |
Tip CurveRadiusmm |
|---|---|---|---|---|---|---|
| Straight Stainless Steel | ||||||
| G02426 | C-SF-15-15 | — | N/A | .015 | 15 | — |
| G02230 | C-SF-15-20 | — | N/A | .015 | 20 | — |
| G02205 | C-SF-15-30 | — | N/A | .015 | 30 | — |
| G02277 | C-SF-15-40 | — | N/A | .015 | 40 | — |
| G02446 | C-SF-18-20 | — | N/A | .018 | 20 | — |
| G02261 | C-SF-18-30 | — | N/A | .018 | 30 | — |
| G02255 | C-SF-18-40 | — | N/A | .018 | 40 | — |
| G01955 | C-SF-18-50 | — | N/A | .018 | 50 | — |
| G02267 | C-SF-21-15 | — | N/A | .021 | 15 | — |
| G02540 | C-SF-21-20 | — | N/A | .021 | 20 | — |
| G02300 | C-SF-21-50 | — | N/A | .021 | 50 | — |
| G02163 | C-SF-25-30 | — | N/A | .025 | 30 | — |
| G05172 | C-SF-25-15 | — | N/A | .025 | 15 | — |
| G01937 | C-SF-25-40 | — | N/A | .025 | 40 | — |
| G01938 | C-SF-25-50 | — | N/A | .025 | 50 | — |
| G01940 | C-SF-35-30 | — | N/A | .035 | 30 | — |
| G03108 | C-SF-28-50 | — | N/A | .028 | 50 | — |
| G01942 | C-SF-35-50 | — | N/A | .035 | 50 | — |
| Safe-T-J Curved Stainless Steel | ||||||
| G06973 | C-SCF-15-30-2 | — | N/A | .015 | 30 | 2 |
| G07182 | C-SCF-18-15-3 | — | N/A | .018 | 15 | 3 |
| G02659 | C-SCF-18-40-2 | — | N/A | .018 | 40 | 2 |
| G02050 | C-SCF-18-50-3 | — | N/A | .018 | 50 | 3 |
| G02180 | C-SCF-25-50-3 | — | N/A | .025 | 50 | 3 |
| G01946 | C-SCF-35-40-3 | — | N/A | .035 | 40 | 3 |
| G01947 | C-SCF-35-50-3 | — | N/A | .035 | 50 | 3 |
| Safe-T-J Curved Stainless Steel with Heparin Coating | ||||||
| G01967 | C-SCF-35-40-3-BH | — | N/A | .035 | 40 | 3 |
| Straight TFE Coated Stainless Steel | ||||||
| G08144 | C-TSF-18-15 | — | N/A | .018 | 15 | — |
| Safe-T-J Curved TFE Coated Stainless Steel | ||||||
| G05651 | C-TSCF-25-40-2 | — | N/A | .025 | 40 | 2 |
